Yeti Cycles SB165 T-Series 29" / 27.5" Frame
Yeti Cycles SB165 T-Series 29" / 27.5" Frame
Yeti Cycles SB165 T-Series 29" / 27.5" Frame
Yeti Cycles SB165 T-Series 29" / 27.5" Frame

Yeti Cycles SB165 T-Series 29" / 27.5" Frame

£4,699.00 GBP
Colour
Size

SB165


We said it already knows. And now it knows better. Proven worthy time and again at Rampage, reconfigured to fit the bill as Zero-Hesitation Go-To for whatever your pleasure. Un-rack it for all the park laps, pedal it on character-building epics, push it up spooky steep darksides “nobody” knows about. Whatever the question, unhard your decisions. YOU ASK. IT GIVES..

165MM

FRAME TRAVEL



170MM

FORK TRAVEL



29"

FRONT WHEEL SIZE



27.5"

REAR WHEEL SIZE



63.5°

HEAD TUBE ANGLE



76.9°

EFF. SEAT ANGLE

HIGHLIGHTS

  • Fox Factory 38 Grip 2 and Fox Factory DHX2 shock
  • Fox Transfer dropper post
  • MX DT Swiss EX1700 custom wheelset
  • 4 piston brakes
  • ODI Elite Pro grips
  • 220mm front and 200mm rear rotors
  • Maxxis Assegai 2.5 and DHR II 2.4 EXO+ tyres
  • SLS Coil Spring on frame only

FRAME HIGHLIGHTS

  • 63.5-degree head tube angle
  • 76.9-degree seat tube angle
  • 165mm rear travel paired with a 170mm fork
  • Sizes: SM-XL
  • Threaded bottom bracket
  • High-clearance downtube
  • Dual-density downtube protection
  • Universal Derailleur Hanger (UDH)
  • Secure, fully enclosed internal cable management
  • Compatible with long dropper posts
  • 100% standard sealed Enduro Max bearings
  • Floating collet axle pivot design
  • Compact-wishbone shock extender
  • Boost spacing

YOU ASK. IT GIVES.

SIZE GUIDE

SMALL 5'1" - 5'7"
MEDIUM 5'5" - 5'11"
LARGE 5'10" - 6'3"
X-LARGE 6'1" - 6'7"

SPECIFICATION

TURQ Series carbon fibre frame, threaded bottom bracket, fully enclosed internal cable routing, 148mm x 12mm BOOST dropouts, integrated derailleur hanger and axle.

FRAME TURQ SERIES
SHOCK FOX FACTORY DHX2 2 POS LEVER (SM:400 MD:450 LG:500 XL:550 STEEL)

Please note: Specifications are subject to change without notice.



GEOMETRY

All measurements are shown in millimetres.


170MM FORK SM MD LG XL
A SEAT TUBE LENGTH 365 400 440 470
B EFF. TOP TUBE LENGTH 573 604 625 653
C HEAD TUBE ANGLE 63.5 63.5 63.5 63.5
D EFF. SEAT TUBE ANGLE 76.8 76.9 76.9 76.9
E CHAINSTAY LENGTH 433 435 437 439
F WHEELBASE 1207 1242 1266 1298
G ESTIMATED BB HEIGHT 345 345 345 345
H STANDOVER 730 738 744 750
I HEADTUBE LENGTH 95 101 107 118
J FORK (AXLE TO CROWN) 588 588 588 588
K FORK (OFFSET) 44 44 44 44
L STACK 620 625 630 640
M REACH 430 460 480 505
N FRONT CENTER 774 807 829 859
O VERTICAL FORK TRAVEL 152 152 152 152
