Yeti Cycles SB135 T-Series 27.5" Frame
Yeti Cycles SB135 T-Series 27.5" Frame
Yeti Cycles SB135 T-Series 27.5" Frame
Yeti Cycles SB135 T-Series 27.5" Frame
Yeti Cycles SB135 T-Series 27.5" Frame
Yeti Cycles SB135 T-Series 27.5" Frame

Yeti Cycles SB135 T-Series 27.5" Frame

£4,299.00 GBP
Colour
Size

SB135


Begging for your input, chomping to respond. Flick it, pedal it, pump it to the moon. A stoke-making mutation of fun-focused DNA, blinding proof that less can be a whole lot more. Come out to play. You bet your ass the SB135 is... still down.

135MM

FRAME TRAVEL



160MM

FORK TRAVEL



14%

LEVERAGE RATE



27.5"

WHEEL SIZE



65°

HEAD TUBE ANGLE



76.5°

EFF. SEAT ANGLE

HIGHLIGHTS

  • Lunch Ride (LR) builds featuring 160mm Fox Factory 36 & Fox Float X
  • Maxxis ASSEGAI 2.5 & DHR II 2.4 EXO+ casing
  • and more powerful brakes with larger rotors
  • Fox Transfer dropper post
  • DT Swiss CUSTOM EX Wheels
  • 4 piston brakes
  • ODI Elite Pro grips
  • 200 front and rear rotor

FRAME HIGHLIGHTS

  • NEW Threaded bottom bracket
  • NEW High-clearance downtube
  • NEW Dual-density downtube protection
  • Universal Derailleur Hanger (UDH)
  • Secure, fully enclosed internal cable management
  • Compatible with long dropper posts
  • 100% standard sealed Enduro Max bearings
  • Floating collet axle pivot design
  • Compact-wishbone shock extender
  • Boost spacing
  • Lunch Ride available in sizes MD-XL

DART. WEAVE. DRIFT.

There's main lines and race lines. And then there's the completely unexpected lines that requires a rider with a different headspace all together. Riders looking to find the fun love of the SB135 for its quick-witted playfulness, agility and its ability to unlock creativity.

SIZE GUIDE

MEDIUM 5'5" - 5'11"
LARGE 5'10" - 6'3"
X-LARGE 6'1" - 6'7"

SPECIFICATION

TURQ Series carbon fibre frame, Switch Infinity suspension technology, threaded bottom bracket, fully enclosed internal cable routing, 148mm x 12mm BOOST dropouts, sealed Enduro Max pivot bearings, integrated derailleur hanger, and axle.

SHOCK FOX FACTORY FLOAT

Please note: Specifications are subject to change without notice.



GEOMETRY

All measurements are shown in millimetres.


160MM FORK MD LG XL
A SEAT TUBE LENGTH 400 440 470
B EFF. TOP TUBE LENGTH 569 621 649
C HEAD TUBE ANGLE 65 65 65
D EFF. SEATTUBE ANGLE 76.5 76.5 76.5
E ACTUAL SEATTUBE ANGLE 71.6 71.6 71.9
F CHAINSTAY LENGTH 433 435 437
G WHEELBASE 1203 1229 1261
H ESTIMATED BB HEIGHT 340 340 340
I STANDOVER 718 721 725
J HEADTUBE LENGTH 107 118 129
K FORK (AXLE TO CROWN) 558 558 558
L FORK (OFFSET) 37 37 37
M STACK 600 610 620
N REACH 455 475 500
O FRONT CENTER 770 794 824
P VERTICAL FORK TRAVEL 145 145 145
