Deviate Claymore

Have you been looking into the Deviate Claymore and are wanting to find out a bit more? look no further than this summery!

The 2024 Edition of the Deviate Claymore maintains its award-winning design while now being fully UDH compatible. Inspired by the medieval Scottish two-handed great sword, known for its strength and symbolism of the rugged Highlands, Deviate’s Claymore embodies this legacy - crafted to conquer the world's most challenging terrains. Whether you're descending root-strewn drops or racing between tapes at dizzying speeds, the Claymore excels. Designed to be the ultimate long-travel enduro bike, it offers unparalleled handling, combining speed, precision, and versatility for both racing and trail riding. The Claymore's goal is to dominate enduro stages with winning pedal performance and playful agility for off-tape adventures.


FEATURES

Rear Wheel: 29”, Boost: 148mm * 12mm

Fork Compatibility: 29” 170 or 180mm with 44/42mm offset | Fork crown interference with downtube MUST be checked before fitting forks

Bottom Bracket: 73mm BSA Threaded

Headset: ZS44/28.6 upper and a ZS56/40 lower headset cup

Cranks: Minimum Q-factor of 168mm

Chainline: 52mm or 55mm options available

Chain length: 126 links (widely available, no need to join chains)

Max Chainring Size: 36t

Shock Size: Metric 230*60mm (Some shocks may be incompatible with our frames, please check this with the shock manufacturer and/or ourselves)

Shock Hardware: Front: 40*8mm | Rear: Eyelet bushing

Brake Mount: Post Mount 180mm

Seatpost Compatibility: Internal dropper routing 34.9”

Seat Collar: 38.5mm

Mech hanger: UDH or Deviate Derailleur Hanger (Highlander/Claymore)

Rear Axle non-UDH : M12xP1.75 | 192mm long | Thread length is 26mm (minimum 20mm)

Rear Axle UDH : M12xP1 | 185mm long | Thread length is 14.5mm
