£5,500.00 GBP
Colour
Size

Fuel LX 9 XT Di2 is a hard-charging trail bike built for rowdy laps and hair-raising descents. It pairs an adaptable Alpha NEXT Platinum aluminum frame with a Fox Factory 38 fork and DHX2 coil shock (160mm rear, 170mm front) for rolling into steeper than steep lines packed with mine fields of boulders. Shimano’s wireless XT Di2 drivetrain delivers ultra-crisp, customizable shifting in a light, robust package, and 4-piston Shimano XT M8220 brakes provide excellent modulation and stop-on-a-dime power.

Technology

Adapt, rip, repeat - Only you can define your perfect trail bike – that's why Fuel is available in three adjustability-packed configurations. Get do-it-all capability with EX, go pop-happy with MX or charge through it all with LX.

Specification

Frame Alpha NEXT Platinum aluminium, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145 mm-160 mm Alpha NEXT P
Frame Material ALUMINIUM
Rim Size 29
Fork Fox
Fork Fox Factory 38, Float EVOL air spring, GRIP X2 damper, 44 mm offset, Boost 110, 15 mm Kabolt X axle, 170 mm travel Fox Factory 38, Float EVOL air spring, GRIP X2 damper, 44mm offset, Boost 110, 15mm Kabolt X axle, 1
Rearsuspension Fox
Suspension Rear Fox DHX2, 205 mm x 65 mm
Wheels Bontrager Line Comp 30
Tires Maxxis Assegai, tubeless ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5" // Maxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 29x2.5" // Maxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 29x2.5"
Shifter Shimano
Derailleur Rear Shimano XT M8250, long cage
Crank Shimano XT 8200, 30T, 55 mm chain-line, 170 mm length // Shimano XT M8200, 30T, 55mm chainline, 165mm length
Bottom Bracket Shimano BB-MT501 BSA
Cassette Shimano XT M8200, 10-51, 12-speed
Chain Shimano XT M8100, 12-speed
Brake Shimano
Brakeset Shimano XT M8220 4-piston hydraulic disc // Shimano XT M8220 4-piston hydraulic disc Shimano XT M8220 4-piston hydraulic disc // Shimano XT M8220 4-piston hydraulic disc
Brake Rotor Shimano RT86, 6-bolt, 203 mm // Shimano RT86, 6-bolt, 180 mm
Saddle Verse Short Comp, steel rails, 145 mm width
Seatpost Bontrager Line Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 515 mm length
Handlebar Race Face Turbine, alloy, 35 mm, 40 mm rise, 780 mm width
Stem Bontrager Elite, 35 mm, 0-degree, 45 mm length
Grips Trek Line Elite, lock-on
Size Chart Rider Height Rider Height - 177.0 - 188.0
Size Chart Rider Inseam Inseam - 84.0 - 89.0
